Yeastar TG series connects GSM/3G/4G-networks directly to VoIP networks and enables bi-directional communication: GSM/3G/4G with VoIP and VoIP with GSM/3G/4G. The TG series is the best available solution to interconnect IP-based PBXs and provides a softswitch connection to a GSM/3G4G network. In addition, it is the best fallback solution when the fixed line fails.

• Connect PBX systems to GSM or 3G WCDMA or 4G LTE networks
• Send and receive SMS messages via web interface, supports bulk SMS
• Save significant phone costs with mobile-to-mobile calls and SIP trunks
• In the web-based management, everything can be set up effortlessly
• Cost-effective backup when landline fails
• Easy to integrate: high compatibility with established IPPBX and softswitch



Technical SpecificationModels*TG100TG200TG400TG800TG1600Number of Ports124816GSM Frequency**850/900/1800/1900 MHzWCDMA Frequency**850/1900 MHz, 850/2100 MHz, 900/2100 MHz4G Data–4G LTE Band**Don’t support 4G LTEDepending on the module type. Check the supported band and operators.Don’t support 4G LTEProtocolSIP, IAX2Antenna Splitter (4 in 1)–SupportTransportUDP, TCP, TLS, SRTPVoice CodecG.711 (alaw/ulaw), G.722, G.726, G.729A, GSM, ADPCM, SpeexDTMF ModeRFC2833, SIP Info, In-bandEcho CancellationITU-T G.168 LECCalling TypeTermination (VoIP to GSM/WCDMA), Origination (GSM/WCDMA to VoIP)Network ProtocolFTP, TFTP, HTTP, SSHLAN1 10/100 Mbps Ethernet Interface2 10/100 Mbps Ethernet InterfacesNAT TraversalStatic NAT, STUNNetworkDHCP, DDNS, Firewall, OpenVPN, Static IP, QoS, Static Route, VLANOperation Range0°C to 40°C, 32°F to 104°FPower SupplyDC 12V, 1AAC 100-240VStorage Range-20°C to 65°C, -4°F to 149°FDimensions (L × W × H) (mm)110 x 70 x 24213 x 160 x 44340 x 210 x 44440 x 250 x 44Humidity10-90% non-condensing
